รายละเอียดสินค้า:
|
| แรงดันไฟฟ้า: | 220V | ขนาดเอาต์พุตสูงสุด: | 1160*880 |
|---|---|---|---|
| สภาพการทำงาน: | เปิดตัวด้วยตนเอง | การกำหนดค่าเครื่อง: | สามารถจองได้ |
| ขนาดภายนอก: | 1500*1200*1250 | จำนวนเลเซอร์: | 64 |
| เน้น: | Manual Launch CTP Plate Machine,CTCP Plate Making Machine 405nm,Environment Friendly CTP Plate Machine |
||
UVCTP machine CTCP machine CTCP plate machine CTP free machine Environment friendly CTCP plate making machine
Processing free plate making machine,
| Technical Parameters | ||||||||||
| Model | Thermal | UV | ||||||||
| T824 | T832 | T848 | T864 | T8128 | U824 | U832 | U848 | U864 | U8128 | |
| NO.of lasers | 24 | 32 | 48 | 64 | 128 | 24 | 32 | 48 | 64 | 128 |
| Throughput(1130*800) | 13 | 18 | 23 | 28 | 45 | 13 | 18 | 23 | 28 | 45 |
| Max.Min.Format | MAX:1160*940 MIN:400*350 | MAX:1160*940 MIN:400*350 | ||||||||
| Laser source | 830nm | 405nm | ||||||||
| Resoiution | 2400DPI | |||||||||
| Loading system | Automatic,Semi-Auto(Optional Auto-loader) | |||||||||
| Plate requirement | CD. 0.15-0.4 (Thermal plate) | CD. 0.15-0.4 UV plate | ||||||||
| Interface | 1-bit Tiff interface and direct workflow driver,support CIP3/CIP4 | |||||||||
| Power | AC220V,50-60HZ 5.5KVA | |||||||||
| Work environment | Temperature:20-25℃,Humility:40%-80% | |||||||||
Mature thermal imaging technology
Thermal plate making machines are known for providing incredible accuracy and stability. Plate making machine goes further:
With imaging technology, you can achieve unmatched stability, reliability and
Accuracy, so as to reduce the number of plate making, reduce variable adjustment time, and improve print quality.
High performance. Low impact.
Plate making machine is an important part of the company's sustainable development strategy. Our latest models help you save power
In prepress, no matter on our previous CTP equipment or in the competition, we will not sacrifice productivity or uptime. Trend setter
The Q400/Q800 tablet only uses 770W power when imaging, 85% lower than some competitors' devices.
It can save energy, water and chemicals before printing, and reduce waste before printing
A printing room with accurate and stable plates
